Product Highlights

• Material: 1.5/1.2mm SUS304
• Size: 1400×300×980mm
• Sensor pairs: 5 pairs
• Pass rate: 35 persons/minute

Parameters

• ✔ Material: 1.5/1.2mm SUS304
• ✔ Size: 1400×300×980mm
• ✔ Sensor pairs: 5 pairs
• ✔ Pass rate: 35 persons/minute
• ✔ Pass width: 600–1100mm
• ✔ Input voltage: 100V~240V
• ✔ Motor type: DC brushless motor
• ✔ Environment: -20℃ to +70℃
• ✔ Power supply: 24V 150W
• ✔ Net weight: 65KG

Features

• ✔ Reasonable and reliable design, low noise, smooth operation, and long service life;
• ✔ Function of opening doors automatically under power-off state to meet the need of fire-fighting passage;
• ✔ Functions of anti-tail, anti-reverse pass, and so on;
• ✔ Card can be set with "memory" or "without memory" functions;
• ✔ Automatic reset function: after accessing the gate, it automatically restores to the locked state if not passed within the set time;
• ✔ Infrared anti-clip function (prevents clipping when the gate is open or running);
• ✔ Compatible with IC cards, ID cards, scanning, face recognition, etc.;
• ✔ Two modes of operation are available: open or closed;
• ✔ Various working modes are available, including two-way card reading and one-way card reading, etc.
