Product Highlights

• Maximum length of Boom: 6 meters
• Boom Rest Stand: Yes (available)
• Arm Material: Aluminium
• Time for Up/down: 6 seconds

Technical Specifications

• ✔ Maximum length of Boom: 6m
• ✔ Boom Rest Stand: Yes
• ✔ Arm material: Aluminium
• ✔ Time for Up/down: 6s
• ✔ Input control signal: Dry contact
• ✔ Ingress protection Degree: IP54
• ✔ Input Interface for: Photocell, Air switch
• ✔ Output interface: Lamp
• ✔ Optional Interface: Access control panel, Stand alone access control, Control button
• ✔ Remote control: Yes, up to 25 meters
• ✔ Mode: Automatic / Manual
• ✔ Incorporated control panel with 3 push buttons (STOP / UP / Down) to control the motor
• ✔ Bumping bounce back: Optional
• ✔ Auto closing time: 0–99s

Power Supply

• ✔ SMPS - Input: AC 220V / 110V, 50Hz / 60Hz
• ✔ Motor power: 90W, 240V AC
• ✔ Dimension (mm): 268 x 348 x 1050
• ✔ Operating temperature: -20°C to +50°C

Features

• ✔ Can control by 3 position switch or by remote control unit,operate 'OPEN','CLOSE' and 'STOP'
• ✔ Spring compression system: accident-proof
• ✔ Motor cooling fan for overheating protection
• ✔ Auto-close feature
• ✔ Manual release (in emergencies)
• ✔ Intensive duty cycle
• ✔ MCBF (Mean Cycles Before Failure): 30 lakh cycles
• ✔ Optional traffic light interface
• ✔ Wire and remote control (upto 25m)
• ✔ RFID and Wigand reader compatibility
• ✔ Biometric compatibility
• ✔ Die-cast aluminium alloy motor (heat dissipation friendly)
• ✔ Optional infrared photocell for anti-bumping
